Hais txog NEWTEK PSA
Ntawm -site PSA Oxygen & Nitrogen Generation Solutions
ntseeg tau. Muaj txiaj ntsig. Yooj yim rau kev khiav lag luam.
NEWTEK PSA tshwj xeeb hauv kev tsim thiab muab khoom ntawm -site PSA oxygen thiab nitrogen generators, xa cov kev daws teeb meem roj txhim khu kev qha thiab muaj txiaj ntsig zoo rau ntau hom kev lag luam.
Peb lub tshuab PSA tau tsim kho kom muaj kev ruaj ntseg, yooj yim ntawm kev ua haujlwm, thiab kev ua haujlwm ntev -, muab cov neeg siv khoom muaj kev vam khom rau cov txheej txheem roj ib txwm muaj.
Yam Peb Muaj
NEWTEK PSA muab cov qauv tsim thiab kho PSA tshuab, suav nrog:
PSA Oxygen Generators
PSA Nitrogen Generators
Integrated cua compression thiab purification systems
Turnkey ntawm -site gas solutions
Peb lub tshuab npog ntau yam ntawm cov nqi ntws thiab qib purity, haum rau kev lag luam xws li kev tsim khoom, kev kho mob, kev ua zaub mov, aquaculture, thiab chaw soj nstuam.
Vim li cas thiaj xaiv NEWTEK PSA
Txhua qhov system yog tsim los nrog kev ua haujlwm hauv siab, ua kom muaj kev ntseeg siab thoob plaws hauv nws lub neej kev pabcuam.
Pov thawj thiab standardized system configurations
Kev ua haujlwm ruaj khov nrog kev ua haujlwm tsis tu ncua
Kev siv hluav taws xob zoo thiab cov nqi khiav haujlwm tsawg
Compact tsim thiab yooj yim installation
Kev xa khoom sai thiab teb kev txhawb nqa
Ntim
Tshawb xyuas sab hauv thiab npaj rau kev xa khoom
Manufacturing & Quality Control
NEWTEK PSA ua haujlwm nrog cov neeg ua haujlwm paub txog kev tsim khoom raws li kev saib xyuas nruj.
Txhua chav ua haujlwm tau txais kev tshuaj xyuas thiab kev sim ua ntej xa khoom kom ntseeg tau tias kev ua tau zoo thiab kev nyab xeeb ntawm kev ua haujlwm.
NEWTEK Advantage
Kev Tshawb Fawb Technology
01
Engineering Tsim
02
Device Fabrication
03
Kev kuaj xyuas
04
Tom qab -muag Service
05
PSA Oxygen Generator Qhov Zoo
PSA oxygen generator yog cov khoom siv tsis siv neeg siab lossis ncaj qha tsim cov pa oxygen los ntawm huab cua los ntawm kev siv zeolite molecular sieve ua ib qho adsorbent, siv lub peev xwm adsorption ntawm oxygen thiab nitrogen sib txawv ntawm molecular sieve nto los ntawm lub hauv paus ntsiab lus ntawm siab adsorption thiab poob siab desorption.
Tsawg kawg siab valve thiab bypass nozzle rau kev pib ceev.
Tsis txhob muaj roj ntau dhau thiab Oxygen molecular sieve puas tsuaj.
Rugged tsim.
Kev ua haujlwm tsis tu ncua (24 teev hauv ib hnub, 7 hnub hauv ib asthiv).
Nws yuav tsis tso tseg kev ua haujlwm vim kev cuam tshuam ntawm huab cua.
Chaw taws teeb pib nres.
Modbus, Profibus Fieldbus thiab Ethernet.
MARTLINK yog lub hnub qub ntse.
Raws li qhov xav tau oxygen siab thiab purity tau hloov kho.
Kev hloov kho purity yog qhov yooj yim heev.
Ua tsis tiav oxygen tshuab.
Standby hom yog tswj xyuas thaum tsis xav tau oxygen.
Lub Sijhawm Sijhawm Modulation Algorithm=Lub voj voog txuas ntxiv hauv Oxygen Demand Sijhawm Sijhawm Sijhawm Sijhawm Sijhawm Sijhawm Oxygen Sijhawm Sijhawm=Txo cov huab cua kom tsawg- tion thaum lub sijhawm xav tau oxygen.
High ceev.
Compact caij nplooj ntoos hlav loaded.
Sab saum toj/hauv qab tshuav nyiaj li cas.
Tiv thaiv los ntawm ib tug tshwj xeeb pressuresensor.
Tsuas yog qhuav cov cua compressed.
Txuas thiab ua si.
Tsis muaj kev tshwj xeeb installation thiab commissioning yog yuav tsum tau.
Tag nrho tsis siv neeg thiab saib xyuas oxygen sensors yog tus qauv.
Yooj yim khaws cia.
93%, 95%, 96%, 97%, 98%, 99%
Siv hauv kev kho mob (xws li pawg ntseeg, chav kho mob ceev thiab chav ua haujlwm)
Kev lag luam (xws li mining, tshuaj lom neeg kev lag luam, yug me nyuam, electronics, papermaking thiab lwm yam kev lag luam)
Kev tiv thaiv ib puag ncig (xws li kev kho cov pa khib nyiab, thiab lwm yam)
Technical Indicators
Oxygen ntau lawm: 1 ~ 300Nm³ / h (Standard State)
Oxygen purity: 93% ± 3% (National standard oxygen cov ntsiab lus)
Oxygen siab: 0.01 ~ 0.5Mpa (Kev ntsuas siab ruaj khov thiab kho tau)
Oxygen dew point: -40℃~ -75℃(Atmospheric Dew Point)
|
Qauv |
Gas ntau lawm (Nm³ / h) |
Kev siv cua (Nm³ / min) |
Imported nominal txoj kab uas hla DN DN (mm) |
Imported nominal txoj kab uas hla DN DN (mm) |
Cua nominal txoj kab uas hla DN
|
Tus tswv L * W * H (mm) |
|
NTK93-1 |
1 |
0.2 |
DN15 |
DN15 |
NT0010 |
800 * 650*1720 |
|
NTK93-2 |
2 |
0.4 |
DN15 |
DN15 |
NT0010 |
950 * 950*1500 |
|
NTK93-3 |
3 |
0.6 |
DN15 |
DN15 |
NT0010 |
1050 * 900*1865 |
|
NTK93-5 |
5 |
1 |
DN 20 |
DN15 |
NT0010 |
1450 * 900*1825 |
|
NTK93-10 |
10 |
2 |
DN 32 |
DN15 |
NT0020 |
1450 * 900*1825 |
|
NTK93-15 |
15 |
3 |
DN40 |
DN 25 |
NTAD-4-0 |
1800 * 950*1940 |
|
NTK93-20 |
20 |
4 |
DN40 |
DN 25 |
NTAD-6-0 |
1850 *1025 * 2100 |
|
NTK93-25 |
25 |
5 |
DN 50 |
DN 25 |
NTAD-6-0 |
2000 *1050 * 2210 |
|
NTK93-30 |
30 |
6 |
DN 50 |
DN 25 |
NTAD-8-0 |
2000 *1050 * 2530 |
|
NTK93-50 |
50 |
10 |
DN 65 |
DN 25 |
NTAD-13-0 |
2200 *1250 * 2720 |
|
NTK93-60 |
60 |
12 |
DN 65 |
DN40 |
NTAD-15-0 |
2250 *1300 * 2850 |
|
NTK93-80 |
80 |
16 |
DN80 ua |
DN40 |
NTAD-20-0 |
2350 *1550 * 3060 |
|
NTK93-100 |
100 |
20 |
DN100 |
DN40 |
NTAD-25-0 |
2500 *1600 * 3330 |
|
NTK93-120 |
120 |
24 |
DN100 |
DN40 |
NTAD-30-0 |
2600 *1700 * 3670 |
|
NTK93-150 |
150 |
30 |
DN150 |
DN40 |
NTAD-40-0 |
4700 *1500 * 2980 |
|
NTK93-180 |
180 |
36 |
DN200 |
DN40 |
NTAD-40-0 |
4700 *1600 * 3370 |
|
NTK93-200 |
200 |
40 |
DN200 |
DN40 |
NTAD-60-0 |
5000 *1600 * 3330 |
|
NTK93-240 |
240 |
48 |
DN200 |
DN 50 |
NTAD-60-0 |
5200 *1700 * 3670 |
Tau Exclusive PSA Thiab VPSA Gas Solutions
Kev nug cov neeg siv khoom theem
Kev kos npe rau theem
Ntau lawm thiab logistics theem
Installation thiab commissioning theem
Tom qab - kev muag khoom thiab kev yuav khoom
Kev nug cov neeg siv khoom
Nug txog cov xwm txheej ntawm daim ntawv thov, cov kev xav tau ntawm kev siv roj, thiab lwm yam, muab cov khoom siv ua ntej, cov lus hais thiab cov ntaub ntawv qhia, thiab kho cov kev daws teeb meem tsim nyog.
Daim ntawv cog lus
Paub meej tias tag nrho cov ntsiab lus tseem ceeb xws li kev ntsuas kev ntsuas, tus nqi, lub sijhawm xa khoom, thiab lwm yam thiab kos npe rau daim ntawv cog lus. Paub meej tias qhov chaw xa khoom tshwj xeeb thiab kev xav tau ntawm cov khoom siv.
Kev tsim khoom thiab Logistics
Kev xa khoom raws sijhawm rau tus neeg siv khoom qhov chaw. Lub tuam tsev logistics yog lub luag haujlwm rau kev taug qab cov txheej txheem kev thauj mus los kom ntseeg tau tias cov khoom tuaj txog nyab xeeb.
Installation thiab commissioning
Cov neeg ua haujlwm txawj yuav teeb tsa thiab kho cov khoom siv ntawm qhov chaw thiab muab cov neeg siv khoom siv kev cob qhia ua haujlwm kom ntseeg tau tias cov neeg siv khoom siv tau zoo.
Peb Case
PSA Oxygen Generator Case Hauv Saudi Arabia
Oxygen Peev Xwm: 100Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
PSA Oxygen Plant Case Hauv Sri Lanka
Oxygen Peev Xwm: 80Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
Oxygen Generation Plant Case Hauv Turkmenistan
Oxygen Peev Xwm: 120Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
Muaj oxygen generator hauv Iran
Oxygen Peev Xwm: 60Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
Muaj oxygen generator hauv Indonesia
Oxygen Peev Xwm: 150Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
Muaj Oxygen Generator Tshuab hauv Zambia
Oxygen Peev Xwm: 150Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
Muaj oxygen generator hauv Syria
Oxygen Peev Xwm: 180Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
Muaj oxygen generator hauv Zimbabwe
Oxygen Peev Xwm: 240Nm3 / Hr
Oxygen Purity: 93% +-3%
Daim ntawv thov: Industrial Oxygen
